High Vacuum Pump

Item #:ASVACCUM

1 year warranty

Our quiet, reliable, and low cost two-stage high vacuum rotary vane pump comes both in 120V and 220V versions with or without a gauge.


Specifications:


Ultimate Vacuum

25 microns/laboratory conditions

Pump Speed

1725 RPM (85 liters per minute)

Motor

½ HP, 110V, 60Hz

Oil Capacity

17 oz. (785cc)

Operating Temperature

30°FF to 170°F

Intake Port

3/8" OD for 3/8" ID Tubing

Dimensions (H x L x W)

11 x 14 x5 ¼ in (27.5 x 35 x 12.5 cm)

Shipping Weight

31 Lbs


Part #

Description

LAV-3

3 cubic feet per minute (85L/m) high vacuum rotatory vane pump, 120V

LAV-3-G

3 cubic feet per minute (85L/m) high vacuum rotatory vane pump with a mounted bourdon type gauge, 120V

LAV-3-220

3 cubic feet per minute (85L/m) high vacuum rotatory vane pump, 220V

LAV-3-220-G

3 cubic feet per minute (85L/m) high vacuum rotatory vane pump with a mounted bourdon type gauge, 220V

PNVACPMP

Vein
Included
Direct Drive
Included
SKU Number Vein Direct Drive Gauge Included Voltage Web Price Quantity Add to Cart
LAV-3 Included Included not incl. 110V
1058.06
Each
LAV-3-220 Included Included not incl. 220V
1089.46
Each
LAV-3-220-G Included Included Included 220V
1167.94
Each
LAV-3-G Included Included Included 110V
1140.98
Each
HIGH VACUUM PUMP-3CFM-110
High Vacuum Pump
0.0000
Each
On Order
Quantity:
