Mini Microcentrifuges

LC-8 Compact Centrifuge

LC-8 series of laboratory centrifuges is uniquely designed to meet a wide range of applications in both the clinical and research laboratory. An eight-position rotor is included and designed to directly accept 10 mL and 15 mL test tubes (conical or round bottom). At the same time, optional adapters are also available for use with all popular sizes of blood collection and culture tubes. Unlike most compact centrifuges in this class, the rotor can be easily removed from the chamber for cleaning.

The back-lit, liquid crystal display provides full control over the set run time and rotational speed. The rotational speed can be set/viewed in rpm or rcf and acceleration/deceleration levels can be easily adjusted in the advanced settings mode.

To ensure safety, the digital microprocessor ensures that the lid has been closed and that the safety lid lock is engaged before starting a centrifugation cycle. In addition, an advanced imbalance detection system constantly monitors the balance and vibration, automatically bringing the rotor to a stop if an imbalance is detected.

Specifications

LC-8 Plus Compact Centrifuge

LC-8 series of laboratory centrifuges is uniquely designed to meet a wide range of applications in both the clinical and research laboratory. An eight-position rotor is included and designed to directly accept 10 mL and 15 mL test tubes (conical or round bottom). At the same time, optional adapters are also available for use with all popular sizes of blood collection and culture tubes. Unlike most compact centrifuges in this class, the rotor can be easily removed from the chamber for cleaning.

The back-lit, liquid crystal display provides full control over the set run time and rotational speed. The rotational speed can be set/viewed in rpm or rcf and acceleration/deceleration levels can be easily adjusted in the advanced settings mode.

To ensure safety, the digital microprocessor ensures that the lid has been closed and that the safety lid lock is engaged before starting a centrifugation cycle. In addition, an advanced imbalance detection system constantly monitors the balance and vibration, automatically bringing the rotor to a stop if an imbalance is detected.

Specifications

Sprint™ 8 Clinical Centrifuge

• 8 Position fixed angle rotor
• Holds all common research and blood collection tubes up to 15 mL
• Fixed at 3,400 rpm, ideal for most coag, plasma (PPP) and urinalysis applications
• Adjustable timer

The Sprint™ 8 includes an eight position, fixed angle rotor for the centrifugation of 10 mL blood tubes (16 x 100 mm), and 15 mL conical tubes (17 x 120 mm). Smaller blood tubes (12 x 75 mm and 12 x 100 mm) are also compatible with the use of optional adapters (C3100-ADP).

With intuitive controls and a large LED display, virtually no programming or setup is required prior to starting a cycle. Simply use the up/down buttons to select the run time and press "START". The safety lid-lock is engaged and the rotor quickly and smoothly accelerates to 3,400 rpm. Once the run time is completed (or the "STOP" button is pressed) the rotor comes to a complete stop and the lid lock is disengaged for removal of samples.

Ideal for Coag, PPP and urinalysis studies.


Accessories:
C3100-ADP        Optional adapter for 5-7 mL tubes, 8/pk

Sprint™ 6H Clinical Centrifuge

• 6 Position horizontal (swing out) rotor
• Holds all common blood collection tubes up to 10 mL
• Designed specifically for blood, urine, and cell separations
• Adjustable timer
• UL Listed

The Sprint™ 6H is a compact centrifuge that includes a six position, swing-out rotor. Prior to centrifugation, tubes are loaded vertically. Once the centrifuge starts, tubes swing to a horizontal position, providing the flat-line separation that is commonly preferred for further analysis.

Designed for use with 10 mL tubes (16 x 100 mm), smaller tubes (12 x 75 mm and 12 x 100 mm) can be centrifuged using the optional adapters (item: C3100-ADP).

With intuitive controls and a large LED display, virtually no programming or setup is required prior to starting a cycle. Simply select the run time and press "START". The safety lid-lock is engaged and the rotor quickly and smoothly accelerates to 3,400 rpm. Once the run time is completed (or the "STOP" button is pressed) the rotor comes to a complete stop and the lid lock is disengaged for removal of samples.


Accessories:
C3100-ADP        Optional adapter for 5-7 mL tubes, 8/pk

• Simple yet feature-rich operation
• Fixed angle, swing bucket and microplate rotor options available
• Numerous safety features
• Accommodates tubes from 0.2mL to 100mL and microplates

The GCC-MP Multi-Purpose Clinical Centrifuge is a large capacity centrifuge that can be used in a variety of clinical lab applications. The GCC-MP is compatible with virtually any tube typically found in the clinical lab environment and can be customized to your specific applications and methods.

Safety Features:

• Door interlock
• Overspeed detector
• Over-temperature detector
• Imbalance protection
• Automatic rotor identification

The GCH-24 Hematocrit Centrifuge allows your lab to determine erythrocyte fractions in blood as well as micro solution separations using the included twenty-four (24) place capillary rotor. The included rotor lids enhance user safety and are easy to remove or replace.

Programming is simple with the backlit LCD display, intuitive control buttons and parameter adjustment knob. The timer will not count down until the programmed speed is reached, ensuring accurate results. Setpoint can be set by G-Force or RPM.

Features:

• Speed range of 200-14,000rpm, max. RCF 18,620 x G
• Independent control of speed and time
• Easy operation with intuitive menu and easy-to-read display
• Maintenance free brushless DC motor
• Pulse operation for quick spins
• Included hematocrit rotor: 24 capillary capacity, max. speed of 12,000rpm
• Optional tube rotor: 24 place 1.5/2mL capacity, max. speed of 14,000rpm
• Includes pulse operation (quick spin)

Advanced Features:

• Speed/RCF switch
• Short-time run function
• Audible alert function

Safety Functions:

• Door interlock
• Overspeed detector
• Over-temperature detector
• Automatic internal diagnosis
• Automatic rotor identification

Technical Data:

Hematocrit Centrifuge Accessories:

GCH-24-ROT-1.5-2:   Rotor for the GCH-24 Centrifuge, 24-Place for 1.5mL/2.0mL, 14000rpm max

GCM-24-AD2:  Rotor Adapters for GCM-12, GCM-24, GCH-24 for 0.2mL Tubes, 24/bag

GCM-24-AD5:  Rotor Adapters for GCM-12, GCM-24, GCH-24 for 0.5mL Tubes, 24/bag

Sprint™ 6H Plus Clinical Centrifuge

• 6 Position horizontal (swing out) rotor
• Holds all common blood collection tubes up to 15 mL
• Digitally set speed in rpm or rcf (up to 4,000 rpm/2,850 x g)
• Adjustable speed and timer
• Safety imbalance detection system

The Sprint™ 6H PLUS is our premium clinical centrifuge offering providing horizontal (swing-out) centrifugation:

Standard Clinical Centrifuge (GCC-S)

The Standard Clinical Centrifuge has been designed for numerous clinical and research applications with simple yet robust features. The included twelve (12) position rotor accommodates 5mL, 7mL or 10mL culture or blood collection tubes and up to eight (8) 15mL tubes (all adapters are included).

The GCC-S clinical centrifuge is compatible with most PRP methods.

An easy to read LED display shows both time and speed and easy easily programmed. The timer will not count down until the set speed is reached to ensure your separations and experiments work as intended. The manual door release is positioned on the side of the unit to ensure the GCC-S remains closed until you want access.

Features:

• Fast acceleration and deceleration
• Speed range of 300-4500rpm
• Independent control of speed & time
• Suitable for numerous clinical and research applications, including separations
• Ideal for use with 15mL centrifuge tubes and most Globe Scientific collection tubes
• Includes fixed angle rotor that holds up to twelve (12) 5mL/7mL/10mL tubes or eight (8) 15mL tubes
• All adapter sleeves and risers included
• Audible alert function

Safety Features

• Door interlock
• Excessive speed detection

Enhanced Clinical Centrifuge (GCC-E)

Building on the solid platform of the Standard Clinical Centrifuge, the GCC-E adds an enhanced user interface with it's easy to read backlit LCD display, high accuracy and automated self-diagnosis on startup. The GCC-E is suitable for numerous clinical and research applications and includes a twelve (12) position rotor that accommodates 5mL, 7mL or 10mL culture or blood collection tubes and up to eight (8) 15mL tubes. All adapters are included

The GCC-E clinical centrifuge is compatible with most PRP methods.

Programming allows for setting by either speed or G-force. A quick spin function enables easy spin downs when a timed program isn't necessary. The added safety of an electric locked lid ensures users don't open the lid to soon after protocol is completed.

Features:

• Simple programming for ease of use
• Intuitive menus with highly legible LCD display
• Rotor speed can be set by RPM or G-force
• Maintenance free motor
• Quick spin function (pulse button)
• Electronic locking safety lid with automatic release
• Automatic self-diagnostics on startup (shows accumulative run time and retains last set parameters)
• Quick acceleration and deceleration
• All adaptor sleeves and risers included
• Audible alert function

Advanced Features:

• Speed / RCF set point
• Pulse function
• Audible alert function

Safety Features:

• Door interlock
• Excessive speed detection
• Automatic self-diagnosis

Technical Data:

GCC Series Centrifuge Accessories

GCC-ADP:  Rotor Sleeves & Risers for GCC Series converts cavities for 5mL, 7mL & 10mL, 24/bag

GCC-AD:  Rotor Sleeves for GCC Series Centrifuges, converts cavities for 5mL, 7mL & 10mL, 12/bag

Sprint™ 8 Plus Clinical Centrifuge

• 8 Position fixed angle rotor rotor
• Ideal for rapid production of serum and plasma
• Unique EZ-Scroll™ touch pad
• Digital speed control in rpm or rcf with adjustable acceleration and deceleration rates (up to 6,800 rpm/4,445 x g)
• Program storage up to 99
• Adjustable speed and timer

Unlike traditional clinical centrifuges the increased speed capability (4445 x g) of the Sprint™ 8 PLUS allows for the separation of serum or plasma in as little as 2-3 minutes. Additional features include:

Hermle Z207-H | Compact Hematocrit Centrifuge

• Unique EZ-Scroll™ touch pad
• High speed, up to 16,058 x g
• Compact, 11 inch wide
• Holds 24 Capillaries

Due to its compact design the Z207-H Hematocrit Centrifuge is the perfect centrifuge for even the smallest of lab spaces. It is equipped with a hematocrit rotor for 24 x capillaries. Accompanied by Hermle's easy to use control panel, the unique EZ-Scroll touch pad, gives you ease of control and a modern feel. An advanced microprocessor controls allow for setting/displaying of the rotational speed in either rpm or RCF in increments of 10. In addition to retrieving saved programs, the easy to use front panel can be used to adjust acceleration/deceleration rates, run time, and change the end of run alarm tone. There is also a momentary spin function that will run while the button is pressed. Additionally, the Z207-H features a sleep mode to save energy by shutting off after a certain time if not being used while on, which can be toggled on or off easily.

Specifications
