I410 Series Inverted Microscopes

I410 Series Inverted Microscopes offer advanced optical technology but in a compact size and at an unmatched price point. These Microscopes are built on the NIS60 optical design—the most advanced optical technology available in this class of scope. These universal optics work in all media types and function in all illumination techniques, making these scopes a powerful laboratory tool. Ergonomic features and design provide a fatigue-free imaging experience.

• Compact, modular design allows seamless integration of peripheral components
• Integrated LED illumination calibrated to 5600 Kelvin-daylight white light with a 25,000-hour lifespan
• NIS60 Infinity-corrected optical system for superior image quality
• Selectable Extra-Long Working Distance (ELWD) Plan Fluorite Phase Contrast, Long Working Distance (LWD) Plan Achromatic Phase Contrast, and Brightfield Objectives
• LWD condenser with slider module and single-phase contrast ring compatible with 10X, 20X, and 40X magnification objectives to streamline the workflow
• Built-in photo port for easy camera mounting and image capture
• Side-facing, 5-position ball bearing objective nosepiece for quick, accurate, and vibration-free objective switching
• Oversized platform stage with optional mechanical stage upgrade
• Optional fluorescence module with 3 position optical filter turret and integrated LED modules for imaging versatility

Configurations include:

• Microscope stand with coarse and fine focus and selectable tension adjustment
• White Light LED with variable intensity
• Eye tube 360 degree rotatable with 2ea 10X UW Eyepieces
• Integrated Photo Port
• Platform Stage with glass stage plate insert for easy objective identification
• 5-Position, ball bearing nosepiece
• Universal condenser with aperture diaphragm and phase slider port
• Phase slider with 3 positions: single phase ring for 10X, 20X, and 40X objectives

Contact us for a quote!

Specifications

Optical System	NIS60 Infinity Optical System
Optical Lenses	Universal Long Working Distance S-Plan Apo, Plan Fluor, Plan Achromat
Illumination	High Luminescent White Light LED
Eco Technology	Integrated--Auto Off
Eyetube	Ergonomic 45 Degree: Binocular
Photo Port	Included/Integrated
Eyepieces  (F.O.V)	10X (22 mm F.O.V) | 15X (16 mm F.O.V) | 20X (12.5 mm F.O.V)
Focusing	Coarse 2 uM / Fine 1 uM Resolution, Coarse Focus Tension Adjustment
Nosepiece	5 Position-Side Accessible
Condenser	ELWD | 0.30NA | 75 mm WD
Contrast Slider	Pre-Centered Phase Slider, Emboss Contrast Slider, Hoffman Modulation Contrast
Stage	Platform 170 x 250 mm (Mechanical Stage Optional)
Fluorescence	Modular and upgradable (Optional)
Dims (D x W x H)	21.38 x 9.57 x 18.50 In. | 543 x 243 x 470 mm
