Implen NanoPhotometer® N120

Item #: ASN120

1 year full coverage warranty

NanoVolume Performance
Detection Range dsDNA 2 - 8,000 ng/µl
Detection Range BSA 0.06 - 230 mg/ml
Sample Volume 2 - 3.5 µl
Photometric Range (10 mm equivalent) 0.04 - 160 A
Path Length 1 and 0.125 mm
Dilution Factor 10 and 80
Processing Power & Compatibility
Operating System Linux based NPOS
Onboard Processor Intel Celeron dual core 2.4 GHz
Internal Data Storage 128 GB
Software Compatibility Windows 7, 8, 10 (32 & 64 bit), OS X, iOS Android OS
Optical Specifications
Wavelength Scan Range 200 - 900 nm
Measure Time For Full Scan Range 1.7 - 2.5 sec per sample
Wavelength Reproducibility ± 0.2 nm
Wavelength Accuracy ± 0.75 nm
Bandwidth < 2.5 nm
Absorbance Reproducibility < 0.004 A (1 mm path) @ 280 nm
Absorbance Accuracy < 1.75% @ 0.7 A @ 280 nm of the reading
Stray Light < 1% @ 240 nm using NaI
Optical Arrangement 1 x 3648 CCD Array
Lamp Xenon flash lamp
Lifetime 109 flashes, up to 10 years
General Specifications
Main Body Size 200 x 200 x 120 mm
Weight 3.8 - 5.2 kg depending on configuration
Operating Voltage 90 - 250 V, 50/60 Hz, 90 W, 18/19 VDC
Display 1024 x 600 pixels; glove compatible touchscreen
Built-in Battery Pack 47.5 Wh, 3.3 Ah, 3 h Min. charging cycles: 800
Certification CE, IEC 61010-1:2012 and EN 61326-1:2013
Battery Certification IEC 62133 and UN38.3 transport test
In & Output Ports 2x USB A, USB B, HDMI, Ethernet, WiFi
Security Slot for Kensington lock
SKU Number Type Battery Touchscreen Vortexer Included Cuvette Port Included Spectrum Read Price Quantity Add to Cart
N120 12-Channel NanoVolume Optional Yes No No 200 - 900 nm
19950.00
Each
N120 Nanophotometer
Implen NanoPhotometer® N120
Special Order
Quantity:
