Home > PCR, Protein, RNA, DNA > Protein > Electrophoresis > Supplies > Accessories > Hoefer® Combs for HE99X Max Horizontal Agarose Systems

Hoefer® Combs for HE99X Max Horizontal Agarose Systems

Item #: ASHOFRCOMBS4

Hoefer® Combs for HE99X Max Horizontal Agarose Systems

Available in multiple tooth configurations and thicknesses to suit various sample volumes and well sizes. Hoefer® combs ensure sharp, consistent, well formation for accurate, reproducible results.

All combs require HE91-BK comb back ordered separately
Preparative combs have 1 preparative well and 2 reference wells
Sample volume listed is for a 5 mm deep well
For use with HE99X Max Horizontal Agarose Systems

Specifications

Item #	Type	Wells	Teeth	Thickness	Width	Sample Vol.
HE91A-P-15	HE99X Comb	1/2 Wells	1/2 Teeth	1.5 mm	113/10 mm	885/72.5 uL
HE91A-P-30	HE99X Comb	1/2 Wells	1/2 Teeth	3 mm	113/10 mm	1710/145.5 uL
HE91A-10-15	HE99X Comb	10 Wells	10 Teeth	1.5 mm	9.7 mm	72.5 uL
HE91A-10-30	HE99X Comb	10 Wells	10 Teeth	3 mm	9.7 mm	145.5 uL
HE91A-15-10	HE99X Comb	15 Wells	15 Teeth	1 mm	7.1 mm	35.5 uL
HE91A-15-15	HE99X Comb	15 Wells	15 Teeth	1.5 mm	7.1 mm	53.5 uL
HE91A-15-30	HE99X Comb	15 Wells	15 Teeth	3 mm	7.1 mm	106.5 uL
HE91A-20-10	HE99X Comb	20 Wells	20 Teeth	1 mm	4.1 mm	23.5 uL
HE91A-20-15	HE99X Comb	20 Wells	20 Teeth	1.5 mm	4.1 mm	35.5 uL
HE91A-20-30	HE99X Comb	20 Wells	20 Teeth	3 mm	4.1 mm	70.5 uL
HE91A-30-10	HE99X Comb	30 Wells	30 Teeth	1 mm	3 mm	15 uL
HE91-BK	HE99X Comb Back and Two Screws
