Grant Digital Ultrasonic Baths

Item #: ASDIGULTRABATH

2 Year Warranty


XUB5
XUB10
XUB12
XUB18
XUB25
Dimensions (h x d x w)
266 x 235 x 345 mm
266 x 220 x 545 mm
365 x 330 x 342 mm
365 x 385 x 375 mm
365 x 385 x 546 mm
Working Capacity
4.5 L
9.5 L
12.5 L
17.5 L
25 L
Max Capacity
5 L
10.5 L
14 L
18.5 L
28 L
Temperature Range
Ambient +5 to 70°C
Ultrasonic Power
100 W
200 W
200 W
300 W
400 W
Ultrasonic Power (per litre)
22.2 W
21 W
16 W
17 W
16 W
Operating Frequency
32-38 KHz
Frequency LEAP
•
•
•
•
•
Heated
•
•
•
•
•
Digital LCD Controls
•
•
•
•
•
SD Port with SD Card
•
•
•
•
•
Timer
0-99 minutes
Drain Outlet BSP Valve
3/8ā€
Heater power – 120V
125 W
240 W
365 W
480 W
600 W
Supply voltage
120 V
Weight
6.4 kg
9.3 kg
10.5 kg
12.6 kg
15.1 kg
ArcticTemp Chest Freezer,

Efficiency and Dependability for the Most Demanding Environments!

Laboratory professionals all over the world are recognizing the dependability and efficiency of ArcticTemp's Ultra Low Freezers, the first to combine all of these performance features and deliver a level of quality construction, reliability and value unequaled anywhere in the world.

Features:

  • Compressor life is extended by an energy-saving low stage (operates only on demand).
  • Compressors are protected with a constant flow of refrigerant.
  • Heat is efficiently and effectively dissipated by an air-cooled condenser with three fans.
  • Monitoring light to warn of clogged condenser.
  • Freezer has an automatic timer system that will restart the unit in case of power failure.
  • Large air-cooled condenser with front to back air flow resulting in cooler compressors.
  • Special hinged grill for easy opening provides for a quick visual check of the condenser.
  • CFC-Free DuPont Suva 95 Refrigerant.

Available Accessories

  • Chart Recorders, 7 Day - 6"
  • Inventory Control Systems
  • Porthole Access
  • CO2 and LN2 Back-Up Systems
  • Stainless Steel Chambers
  • Baskets - Rails
  • Three-Phase Electrical Wiring
  • Power Booster - Low Voltage Safety System
  • Telephone Alarm System

Freezers are also available for -20, -30, -40 and -96°C.

Specifications

Temp Range -40°C to -85°C
Control System Large Digital Temperature Control
Refrigeration System Cascade Type - Two Compressors
Hermetic Type - Condenser - Air-Cooled - Cooling Coils -Copper Tubing
Insulation CFC Free - Minimum 5" High Density
Polyurethane - Minimum 3/4"
Sublids Gaskets - Double-Sealed
Construction Inner Chamber - Heavy Gauge Corrosion
Resistant Zinc Coated Galvanized Steel
Outer Shell - Heavy Gauge, Cold-Rolled Steel
Electrical Requirements 115 volts, 60 hertz, 1 phase
208 volts, 60 hertz, 1 phase
230 volts, 60 hertz, 1 phase
220 volts, 50 hertz, 1 phase
Digital Alarm System Rechargeable lifetime battery powered alarm system has a digital display. An audio and visual alarm will come on when there is a rise in the temperature set point. The system has an audio silence button, alarm test switch, and relay for remote alarm.
Warranty

1 year parts and laborĀ

MIDSCI is not responsible for lost product or damages incurred to product in the case of freezer or refrigerator malfunction.

** V80-30 is only -80


Dimensions of all units

Catalog # Interior Dimensions (W x F-B x H) Exterior Dimensions (W x F-B x H)
V85-13 20" x 22" x 51-1/4" 35" x 33" x 79"
V85-18 23" x 26" x 51-1/4" 36" x 35-1/2" x 79
V85-22 28-1/2" x 26" x 51-1/4" 41-1/2" x 35-1/2" x 79"
V85-25 34" x 25" x 51-1/4" 49" x 35-1/2" x 79"
V80-30 42" x 25" x 49" 62" x 35-1/2" x 79"
H85-5 30" x 18" x 16" 34" x 27" x 47"
H85-9 47" x 16" x 20" 58" x 30" x 47"
H85-12 55" x 19" x 20" 65" x 35" x 46"
H85-14 61" x 20" x 20" 71" x 35" x 46"
H85-17 69" x 20" x 21" 79" x 35-1/2" x 48"
H85-22 67" x 19" x 30" 95-1/2" x 35-1/2" x 44"
H85-27 67" x 23" x 31" 95-1/2" x 35-1/2" x 44"


SKU Number Capacity/Volume Style Price Quantity Add to Cart
XUB5-US 4.5 L Digital Ultrasonic Bath
2824.00
Each
XUB10-US 9.5 L Digital Ultrasonic Bath
3126.00
Each
XUB12-US 12.5 L Digital Ultrasonic Bath
3713.00
Each
XUB18-US 17.5 L Digital Ultrasonic Bath
4157.00
Each
XUB25-US 25 L Digital Ultrasonic Bath
5014.00
Each
Ultrasonic Bath
Grant Digital Ultrasonic Baths
Special Order
Quantity:
