Operating features

• 5° above room temperature to°

• Microprocess PID control/ Auto-tuning/ Calibration

• Digital timer: 1 min to 99 hr 59 min, delayed ON/ OFF

• Over-temperature limiter and low fluid level protection

• 3 different temperature values memorable without auto-tuning

• Digital LED display (0.1° resolution) with splash-proof keypads
• RS-232 interface available



Constructional features

• Exclusive variable-speed pump to liquid viscosity for accurate, stable, and efficient temperature management
  (1 to 3 steps of pump for internal circulation/ 4 and 5 steps for external circulation)

• Powerful pressure and suction pumps provide contrast pressure and flow rate over the full temperature range

• Baffle plate screens circulating pump, heater and sensor to minimize shaking bath fluids and protect sample and
  operators from direct contact

• Dry-running protection; automated heating element cut-off and audible and visual warning

• Seamless stainless steel tank with a reservoir drain that resists corrosion and make cleaning easy

• Space saving design uses minimal bench space

Model CW-05G CW-10G CW-20G CW-30G Bath volume (L/cu ft) 5.0 / 0.2 10.0 / 0.4 20.0 / 0.7 30.0 / 1.1 Working Temperature Range2)( °) Amb. +5 to 150 / Amb. +9 to 302 Temperature Stability 1)(±1°) 0.05 / 0.09 0.05 / 0.09 0.1 / 0.18 0.1 / 0.18 Pump Max. pressure, max. flow rate 5.9 PSI (406.8 millibar), 7.4 gallons/minute (28.0 liters/minute) Max. suction flow rate 2.6 gallons/minute (10.0 liters/minute) Dimensions Bath opening/ depth  (WxL, D) (mm/inch) 150x99, 160 / 5.9x3.9, 6.3 211x154, 180 / 8.3x6.1, 7.1 290x214, 200 / 11.4x8.4, 7.9 300x264, 230 / 11.8x10.4, 9.0 Overall  (WxLxH)(mm/inch) 220x395x424 / 8.7x15.6x16.7 281x450x444 / 11.1x17.7x17.5 360x510x464 / 14.2x20.1x18.3 370x560x494 / 14.6x22.0x19.4 Net weight(kg/lbs) 12.5 / 27.6 15.0 / 33.0 17.5 / 38.6 19.5 / 43.0 Electrical Requirements (230V, 60Hz) 50/60Hz, 4.5A 50/60Hz, 6.7A 50/60Hz, 8.8A 50/60Hz, 8.8A Cat. No. AAH52305K AAH52315K AAH52325K AAH52335K Electrical Requirements  (120V, 50Hz) 50/60Hz, 8.6A 50/60Hz, 8.6A 50/60Hz, 8.6A 50/60Hz, 8.6A Cat. No. AAH52306U AAH52316U AAH52326U AAH52336U

1) If you operate the unit in 1 to 3 steps of pump, the temperature range can be from Amb. +5° but in 4 and 5 steps,
the range will be from Amb. +15°.
2) The heat-up time is measured on a 230V electrical condition with 1000W heater power.
